LNG & Chemical Industry Pipe

The main materials include the reinforced fiber-glass from PPG company and Owens Coming company and the epoxy resin from the American DOW company and the domestic large enterprises.

Product description Technical performance indicator Pipe diameter and grade pressure Physical chemistry

Rated Pressure Range:

≤ 5.5MPa

Curing Series:

Acid Anhydride - cured system Aromatic Amine - cured system

Max. Operating Temperature:

120℃

Diameter Range:

1½" - 40" (40mm - 1000mm)

Product Characters:

◇ High pressure resistance, corrosion resistance, long service life

◇ Meeting the requirements of Jet Fire in ASTM F1173

◇ Anti-static

◇ Low friction coefficient, no-scale, excellent hydraulic characteristic

Application:

◇ Fire water pipeline for LNG Terminal

◇ Sea water pipeline

◇ Bittern water pipeline

◇ Potable water and sewage pipeline

Raw material:

The main materials include the reinforced fiber-glass from PPG company and Owens Coming company and the epoxy resin from the American DOW company and the domestic large enterprises.

Effectively audit operator in process:

Pipe is manufactured using computer-controlled equipment, so that it can meet industry’s ever more exacting needs for quality products and services, it is also certificated with ISO 9001.

Acceptance Control:

Each pipe will have the pressure test by using the automatic press machine, in order to make sure all the pipes and fittings are qualified.

Note:

The company reserves the right to change the specifications and technical data and the instructions and graphic materials. The data is only a general introduction rather than some kind of guarantee.
